Cragg Vale: slim-line gate number 1
In ideal conditions, Andy and Frank H re-configured access to the footpath (Hebden Royd 119) that branches off the minor side road running south over Bod Bridge just beyond the Hinchliffe pub. (see map).
The task was to replace an awkward rail-stile with a pedestrian gate. This would provide an easier alterative to both the existing 'stile' and to the adjacent field gate the latter being particularly heavy and difficult to close.
Today's work was funded by the landowners. Many thanks.
The detail
 |
1 Map: Location of worksite shown by 'blue' tag. Bod Bridge crosses the river about 150 m to the north. |
The following shows the original access. The rail-stile is secure but awkward to climb especially with a 'step-down' on the other side. The side-uprights are very firmly embedded and vertical enough to suggest a gate could be fitted into the gap. What will happen, however, to the overall stability when the cross-rails are removed could be the most interesting technical moment of the day!
 |
2. Original awkward pedestrian access. (The field gate to the right swings back heavily under its own weight). |
Work began by installing side-rails to anchor the original uprights to the wall-end and to the stone pillar respectively. This meant that when the cross-rails were removed the uprights would stay in place and could then act as hinge-post and closure-post for the new gate.
 |
3. Work in progress: Extra bracing side-rails being fitted |
 |
4. Finished job: view from lane side. New side-rails on LHS. Closure spring and closure loop fitted. |
 |
5. Finished job: view from field side. The 'step-down' is no longer problematic. |
The field gate was originally closed by a rope loop over one of the side uprights (see picture 2). The strain, however, on the upright was considerable so a hook was fixed into the stone pillar to act as a safer alternative. Additionally a rock-anchor ring was drilled into the pillar so, if needed, the field gate could be chained shut.
We were happy with the outcome. The gate constructed in CROWS' workshop fitted the gap exactly and the structure is safe, secure, functional . . . and aesthetically pleasing!
100 m down the track is a similar(ish) situation - a narrow pedestrian gap by 'an-often-left-open' field gate. Guess what next week's task will be!
